Combiner

Hybrid Combiner is a radio frequency device that combines signal synthesis and phase adjustment functions, mainly used in microwave and millimeter wave communication systems. Its core functions include:
1.Signal synthesis and distribution
Hybrid Combiner is capable of combining multiple signals while maintaining amplitude and phase relationships, making it suitable for signal allocation in multiple input multiple output (MIMO) systems. When the input signals are of the same frequency and phase, the output power is 3dB higher than the input; when they are of different frequencies, the output power is 3dB lower than the input
2.Phase adjustment characteristics
This device can adjust the phase difference of the output signal, for example, when two signals of the same frequency are input, the output phase difference is 90 degrees. This characteristic makes it play a crucial role in scenarios that require phase control, such as beamforming.  ‌
3.Application scenarios
Mainly used in base station antenna systems, radar systems, and RF links that require signal synthesis. For example, in the frequency range of 698-2700MHz, the Hybrid Combiner can achieve efficient power synthesis and phase control, meeting the performance requirements of communication systems.
