18G-SSMAF-FM1
18G-SSMAF-FM1
Standard Connector,SSMA female,2-Holes flange mounted
1.2g/pcs，20 PCS per package
Item No. 18G-SSMAF-FM1
18G-SSMAF-FM1
18G-SSMAF-FM1
Standard Connector,SSMA female,2-Holes flange mounted
1.2g/pcs，20 PCS per package
Packaging & Delivery
-
Product size
15.25 x 4.7 x 12.18 mm
-
Product weight
1.2 g
-
CTN. Spec
11*11*5 mm / 50
-
G.W/N.W
0.5 / 0.5 kg
Standard Connector,SSMA female,2-Holes flange mounted | ||
| P/N: 18G-SSMAF-FM1 | ||
Applications • Product testing. |  |
Download datasheet |
| Technical Data | ||
| Electrical Data | ||
| Impedance | 50 Ω | |
| Interface frequency (max.) | DC to 18GHz | |
| VSWR | ≤1.2(@18GHz) | |
| Dielectric Withstanding Voltage | 750V rms, 50Hz | |
| PIM | Na | |
| Mechanical Data | ||
| Number of mating(cycles) | ≥500 | |
| Interface | To meet SSMA Type | |
| Weight6 | 1.2g/Pc | |
| Environmental Data | ||
| Operating Temperature(°C) | -40 to 155 | |
| Salt spray test | 48H | |
| 2002/95/EC (RoHS) compliant | ||
| Connector Data | ||
| Piece Parts | Material | Surface Plating |
| Centre contact | BeCu | Gold |
| Out contact | Na | Na |
| Body/Nut | Stainless Steel | Passivation |
| Insulator | PTFE | Na |
| Sealing gasket | Na | Na |
| Outline Drawing | ||
 | ||
Certificate
QUONTEK painstaking research of the IEC/ISO/SGS/ROHS and other international and domestic standards, and in accordance with these standards preparing their own more stringent corporate standards.
Packing&Shipping
Packing Details:
1. PE bag/box + Carton: 100 pieces/bag+200 pieces/box standard packing or as your request
2. Carton size:17*17*7(CM) / 35*35*22 (CM)
Shipping Methods:
1. Samples and Small quantity order FedEx/DHL/UPS/TNT/SF ,Door to Door.
2. Batch goods : Express, By Air
3. FCL: Airport/Seaport/Railway Station receiving Lead Time: 1-7 working days for samples; 15-21 working days for mass
Precautions: To ensure that the product is fully adapted, please confirm the datasheet and
related technical parameters before placing the order.
related technical parameters before placing the order.
Company Introduction
QuonTek (Ningbo) Co., Ltd. is one of Chinese members of IEC International Electronic Standards Committee. With 15 years of research and development in the RF&MW industry, QuonTek devotes itself to the R&D, manufacturing and saling of connectors, adapters and test cables of high frequency, low intermodulation (Low-PIM), and highdemand custom types . It is committed to the creation, innovation and improvement of RF&MW industry. Our products are widely used in base stations, aerospace, aviation, military weapons and equipment,medical equipment, testing equipment and other fields.
FAQ
Do you have questions about specific RF products or product applications? Do you want to know if we can build a special coaxial cable assembly specific to your requirements? Do you have a unique RF technical problem that you're trying to solve?
No problem. We can help! Quontek offers customers FREE expert RF Technical Support from highly skilled in-house engineering staff. Our RF engineers have decades of experience and are here to help answer all of your RF/Microwave-related questions. Whether you're looking for additional product data, having trouble locating your parts online or in our catalog, curious as to how to use a particular product, or need to build a custom assembly and not sure how, Quontek's Technical Support staff can assist you - no matter what!
No problem. We can help! Quontek offers customers FREE expert RF Technical Support from highly skilled in-house engineering staff. Our RF engineers have decades of experience and are here to help answer all of your RF/Microwave-related questions. Whether you're looking for additional product data, having trouble locating your parts online or in our catalog, curious as to how to use a particular product, or need to build a custom assembly and not sure how, Quontek's Technical Support staff can assist you - no matter what!
Q1: Are you a factory or a trade company?
A1: We are factory specialised in kinds of Microwave & mmWave components.
Q2: Where are you located?
A2: We are in Ningbo city, near Shanghai.
Q3: How many years have you engaged in this business?
A3: We have engaged in this business more than 2 years, and we are professional in RF cables, RF cable assemblies, RF coaxial connectors, RF adapters, and kinds of Microwave & mmWave components.
Q4: How long is your delivery time(lead time)?
A4: Within 5 days if the product is in stock, otherwise will take about 20days, after receiving the deposit.
Q5: What’s the MOQ (Minimum Order Quantity)?
A5: Generally speaking 10pcs, but it depends on models.
A5: Generally speaking 10pcs, but it depends on models.
Q6: How many workers do you have?
A6: About 100.
Q7: It is all right to add our logo on your products?
A7: Yes, we can do printing logo or laser logo.
Q8: Why choose us?
A8: As a professional supplier for microwave components more than 10 years, we win our clients with good quality and competitive price. QC inspection before shipping, strong quality control process.
Q9: What are your main products ?
A9: RF cables, RF cable assemblies, RF coaxial connectors, RF adapters and etc.
