Low PIM Cable Assembly,4.3-10 RA male to 4.3-10 female flange mounted with .141" Cable
Low PIM Cable Assembly,4.3-10 RA male to 4.3-10 female flange mounted with .141" Cable
XXg/Pc, Singal Package.
Packaging & Delivery
-
Product weight
0.05 kg
-
CTN. Spec
350*350*200 mm / 100PCS
-
G.W/N.W
15 / 14.5 kg
Low PIM Cable Assembly,4.3-10 RA male to 4.3-10 female flange mounted with .141" Cable，L=XXmm | |||
| P/N: 4310MRA-141FEP-4310FFM-L | |||
Applications • Product testing. |   |  Download datasheet | |
| Technical Data | |||
| Electrical Data | |||
| Impedance | 50 Ω | ||
| Interface frequency (max.) | DC to 6GHz | ||
| VSWR | ≤1.15(@3.6GHz), | ||
| Insert Loss | 1.05*L*dB/m+0.1*√f（See below cable Attenuation） | ||
| Dielectric Withstanding Voltage | 1000V rms, 50Hz | ||
| Mechanical phase | NA | ||
| Amplitude stability | NA | ||
| PIM | -160dBc | ||
| Mechanical Data | |||
| Number of mating(cycles) | ≥500 | ||
| Interface | To meet 4.3-10 Type | ||
| Weight | xx g/Pc | ||
| Environmental Data | |||
| Operating Temperature(°C) | -40 to 155 | ||
| Salt spray test | 48H | ||
| 2002/95/EC (RoHS) compliant | |||
| DIN male Connector Data | |||
| Piece Parts | Material | Surface Plating | |
| Centre contact | Brass | Silver | |
| C-Ring | Bronze | Na | |
| Body | Brass | Tri-Metal | |
| Nut | Brass | Tri-Metal | |
| Insulator | PTFE | Na | |
| Sealing gasket | Silicone rubber | Na | |
| Cable Data | |||
| |||
| No. | Item | Material | Diameter（mm） |
| 1 | Inner conductor | Stranded silver plated copper | 0.94 |
| 2 | Dielectric | PTFE | 3.00 |
| 3 | Outer conductor | Tinned soaked copper braid | 3.52 |
| 4 | Jacket | Blue FEP | 4.10 |
| Cable Electrical，Mechanical and Environmental Data | |||
| 1 | Impedance(ohm) | 50 | |
| 2 | Velocity(%) | 70 | |
| 3 | Operation frequency(GHz) | 34 | |
| 4 | Time delay(ns/m) | / | |
| 5 | Capacitance(pF/m) | 95.1 | |
| 6 | Inductance(uH/m) | / | |
| 7 | Dielectric breakdown Voltage(V,AC 50/60Hz,1 min) | 1900 | |
| 8 | Screening Effectiveness(dB) | 90 | |
| 9 | Peak power(kW) | / | |
| 10 | Mechanical phase(°) | na | |
| 11 | Amplitude stability(dB) | na | |
| 12 | Operating temp.(℃) | -55 to 125 | |
| 13 | Storage temp.(℃) | -40 to 85 | |
| 14 | Min. bend radius, static(mm) | 8 | |
| 15 | Min. bend radius, repeated(mm) | 400 | |
| 16 | Weight (g/m) | / | |
| 17 | RoHS | Compliant | |
| Cable Attention & Average power | |||
| Attenuation Max @ 25℃ | Average power@ 25℃ for cable, at sea level | ||
| Frequency（GHz） | dB/100m | dB/100Ft | Watts(max) |
| 0.5 | 26 | 7.9 | 436.5 |
| 1.0 | 39 | 11.9 | 303.4 |
| 5.0 | 92 | 28.0 | 126.7 |
| 10.0 | 138 | 42.1 | 85.5 |
| 20.0 | 210 | 64.0 | 56.6 |
| 4.3-10 Connector Outline Drawing | |||
   | |||
| Cable Assembly Outline DrawingOutline Drawing | |||
 | |||
Certificate
QUONTEK painstaking research of the IEC/ISO/SGS/ROHS and other international and domestic standards, and in accordance with these standards preparing their own more stringent corporate standards.
Packing&Shipping
Packing Details:
1. PE bag/box + Carton: 100 pieces/bag+200 pieces/box standard packing or as your request
2. Carton size:17*17*7(CM) / 35*35*22 (CM)
Shipping Methods:
1. Samples and Small quantity order FedEx/DHL/UPS/TNT/SF ,Door to Door.
2. Batch goods : Express, By Air
3. FCL: Airport/Seaport/Railway Station receiving Lead Time: 1-7 working days for samples; 15-21 working days for mass
Precautions: To ensure that the product is fully adapted, please confirm the datasheet and
related technical parameters before placing the order.
related technical parameters before placing the order.
