NEX10MRA-141-SD-160

Low PIM connector,NEX10 R/A Male for .141"/RG402/TFT402 cable,solder type

9.1g/Pc, Singal Package.

Message

Send

Have chosenThere are no options selected.

Start To Order

Add To Cart Successfully!

SEND INQUIRY

NEX10MRA-141-SD-160

Name: NEX10MRA-141-SD-160
Brand: QUONTEK
SKU: NEX10MRA-141-SD-160

Low PIM connector,NEX10 R/A Male for .141"/RG402/TFT402 cable,solder type

9.1g/Pc, Singal Package.

Tag Low PIM connector NEX10 R/A Male .141"/RG402/TFT402 cable solder type

Item No. NEX10MRA-141-SD-160

Add to Cart

Inquiry

NEX10MRA-141-SD-160

Low PIM connector,NEX10 R/A Male for .141"/RG402/TFT402 cable,solder type

9.1g/Pc, Singal Package.

Packaging & Delivery

Product size

2.33 x 1.2 x 1.2 mm
Product weight

9.1 g
CTN. Spec

11*11*5 mm / 20
G.W/N.W

0.5 / 0.5 kg
Selling Units

0.0091kg
Single package size

1.2X1.2X3.38 cm
Single gross weight

Single item
Lead Time

Quantity(Pieces) 1 - 50 51 - 500 >500 Est. Time(days) 7 21 To be negotiated

Ceramito Premium Ceramic Insulated Mug

Item No.

GL-112-2

MOQ

100 Piece

Product Size

6.8X6.8X21 Cm

Product Weight

430G

CTN. Spec

47*47*26.5Cm/25

G.W/N.W

13/11Kg

Ceramito's Premium Ceramic Insulated Mug Adds Elegance And Comfort To Your Daily Life. With A High-Quality Ceramic And Stainless Steel Double-Layer Design, It Ensures Every sip Stays At The ldeal Temperature,Maintaining Insulation For Both Hot And Cold Drinks.

1. Double-layer Insulation Design:

Stainless Steel Exterior And Exquisite Ceramic Interior Ensure Long-Lasting Temperature Retention.

Efficient Insulation, Sustaining Temperature For Over 6 Hours.

2. Health And Environmental Materials:

Beverages, Preserving Pure Taste.Beverages, Preserving Pure Taste.

100% BPA-Free For Health Safety.

3. Humanized Design:

Ergonomic Cup Design For Comfortable Grip And Slip Resistance.

Unique Sealable cup Cover Design Prevents Leaks, Easy To Carry.

4. stylish Appearance:

Various Colors And Patterns Available To Meet Individual Preferences.

Crafted With Advanced Techniques For Exquisite Appearance And Delicate Feel.

5. Easy To Clean:

Wide Mouth Design For Easy Cleaning, Smooth Inner Liner Resists stains.

Dishwasher Safe For Time- Saving Cleaning.

6. Ceramic Craftsmanship:

High-Quality Ceramic Liner From Jingdezhen, China, With A Century of Heritage And Exquisite Craftsmanship.

lightweight And Durable Cup Body, Combining Beauty And Practicality.

Low PIM connector,NEX10 R/A Male for .141"/RG402/TFT402 cable,solder type
P/N: NEX10MRA-141-SD-160
Applications • Product testing. • Engineering transfer. • Communication transmission. • Intermodulation test		Download datasheet
Technical Data
Electrical Data
Impedance		50 Ω
Interface frequency (max.)		DC to 6GHz
VSWR		≤1.15(@3GHz)，≤1.25(@3-6GHz)
Dielectric Withstanding Voltage75		750V rms, 50Hz
PIM		≤-160dBc
Mechanical Data
Number of mating(cycles)		≥500
Interface		To meet NEX10 Type
Weight11		8.6g/Pc
Environmental Data
Operating Temperature(°C)		-40 to 155
Salt spray test		48H
2002/95/EC (RoHS) compliant
Connector Data
Piece Parts	Material	Surface Plating
Centre contact	Brass	Silver
Outer contact	BeCu	Silver
Body/Nut	Brass	Tri-Metal
Insulator	PTFE	Na
Sealing gasket	Silicone rubber	Na
Outline Drawing

Nex10 R/A Male Low PIM Connector Solder Attachment for .141", TFT402

NEX10MRA-141-SD-160 type NEX10 R/A male coaxial connector has an interface type of .141“, RG402，TFT402 and a 50 Ohm impedance. Quontek type NEX10 R/A male connector uses shield/contact solder/solder as an attachment method. Our male type NEX10 coaxial connector provides a minimum frequency of DC and a maximum frequency of 6 GHz.

The Quontek NEX10 type R/A male coaxial connector has a PTFE dielectric type and a VSWR of 1.25. The Quontek NEX10 type coaxial connector has a brass body with silver plating. Our NEX10MRA-141-SD-160 NEX10 type connector uses Beryllium bronze contact. This type NEX10 R/A male coaxial RF connector is REACH compliant.

Certificate

QUONTEK painstaking research of the IEC/ISO/SGS/ROHS and other international and domestic standards, and in accordance with these standards preparing their own more stringent corporate standards.


Packing&Shipping

Packing Details:1. PE bag/box + Carton: 100 pieces/bag+200 pieces/box standard packing or as your request
2. Carton size:17*17*7(CM) / 35*35*22 (CM)

Shipping Methods:
1. Samples and Small quantity order FedEx/DHL/UPS/TNT/SF ,Door to Door.
2. Batch goods : Express, By Air
3. FCL: Airport/Seaport/Railway Station receiving Lead Time: 1-7 working days for samples; 15-21 working days for mass

Precautions: To ensure that the product is fully adapted, please confirm the datasheet and
related technical parameters before placing the order.
